Electrical Panels

Electrical Panels

Mehta Power manufacture a wide range of LT Panels as per Indian Standards. We offer Panels with diverse specification options for a highly customzed panels upto 6300 amps having fixed and draw out types, including single/double front type. The LT Panels conform to IS 8623-part 1:1993 & IEC 439-1:1985.
Our panels are designed to withstand high humidity, temperature, ambient service conditions and short circuits levels & these make our panels an ideal choice.
Our panels provides superior control & protection of low voltage power equipment & circuits in utility, industrial, commercial installations involving generators, motors, feeder circuits and distribution.

LT Panels

An electrical distribution board that receives power from generator or transformer and distributes the same to various electronic devices and distribution boards. Such panels are used in industries both for internal and external use and therewfore are quite rugged to withsatnd different climatic conditions. Our LT Panels are designed to work with low electricity consumption that makes them cost effective.

Sychronizing Panels

These panels work between two or more different power sources like DG sets to manage power supply. Synchronization helps in making different DG sets behave as a virtual single unit and eliminates sub-division of total load. It helps in transferring loas from one unit to another as during service period, so that the unit requiring service can be easily shut off. In this way the critical load need not be interrupted and there is no production loss. During low load we can run any single unit and synchronize more units as the load increases automatically.

Salient Features

• Fully compartmentalized design
• Easy to install, operate & require very less maintenance
• Cost Effective & Space Saving
• A high degree of Safety & operational reliability is achieved
• Tailored Configuration to meet client's requirements
• Aesthetically enhanced look & designed to suit client's requirement
• Designed to meet temperature rise limits

Safety

• Completely enclosed bus bar chambers
• Shrouded links in feeder compartments
• Dust & vermin proof construction
• Bus bar constructions to withstand high fault levels upto 70 KA
